Placa de baza Gigabyte X870I AORUS PRO ICE, Socket AM5, DDR5, Mini-ITX
1.688 09 RON
(TVA inclus)
Costurile de livrare nu sunt incluse
Cum te putem ajuta?
Descriere
Placa de Baza GIGABYTE X870I AORUS PRO ICE AM5, 2x DDR5, 1x USB4 1x HDMI, 1x PCIE x16, 2x M.2, 2x SATA 6GB/s, mini-ITX
Ce spun clientii
Detii sau ai utilizat produsul?
Posteaza review
Detalii
SKU
X870I AORUS PRO ICE
Categorii
Brand
PCI Express x16 (Gen 5.x) slots
1
Line-in
Yes
PCI Express x16 (Gen 4.x) slots
1
PCI Express x1 (Gen 3.x) slots
1
Number of SATA III connectors
2
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity
2
Batteries included
Yes
Lithium weight per battery
0.07 g
Battery type
CR2032
ACPI version
5.0
Desktop Management Interface (DMI) version
2.7
System Management BIOS (SMBIOS) version
2.7
BIOS type
UEFI AMI
BIOS memory size
256 Mbit
Clear CMOS jumper
Yes
1st M.2 highest PCI Express generation
5.0
2nd M.2 highest PCI Express generation
4.0
PC health monitoring
Fan, Temperature, Voltage, Water cooling
Power source type
ATX
Motherboard chipset family
AMD
Audio output channels
7.1 channels
Parallel processing technology support
Not supported
DirectX version
12.0
Maximum resolution
4096 x 2160 pixels
Front panel connector
Yes
Number of CPU fan connectors
2
TPM connector
Yes
RGB LED pin header
Yes
Number of EPS power connectors (8-pin)
1
Front panel audio connector
Yes
ATX Power connector (24-pin)
Yes
CPU fan connector
Yes
EPS power connector (8-pin)
Yes
Memory slots type
DIMM
Unbuffered memory
Yes
Supported memory types
DDR5-SDRAM
Maximum internal memory per slot
64 GB
ECC сompatibility
Non-ECC
Antenna included
Yes
Screws included
Yes
DVI-D ports quantity
0
Processor socket
Socket AM5
Supported processor sockets
Socket AM5
Compatible processor series
AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series
WiFi-AP antenna jack
2
Supported storage drive types
HDD & SSD
Number of M.2 (M) slots
2
1st M.2 largest key size
2280
2nd M.2 largest key size
2280
USB 3.2 Gen 1 (3.1 Gen 1) connectors
1
Number of memory slots
2
USB 2.0 connectors
1
PS/2 ports quantity
1
Number of water pump connectors
1
USB 3.2 Gen 2 (3.1 Gen 2) connectors
1
Ethernet interface type
2.5 Gigabit Ethernet
Chassis intrusion connector
Yes
Number of RGB LED pin headers
3
LAN controller
Realtek RTL8125
RAID levels
0, 1
Number of storage drives supported
4
Number of HDDs supported
2
Number of chassis fan connectors
1
Supported memory clock speed (max)
8400 MHz
Supported memory clock speeds
6400,6200,6000,5600,5200,4800,4400 MHz
USB4 Gen 2x2 ports quantity
1
Motherboard form factor
Micro ITX
PCI
0
Serial-or-Paralel
Yes/No
Onboard-CPU
No
Wi-Fi
Yes
Depth
170 mm
Weight
1.2 kg
Width
170 mm
Height
35 mm
Component for
PC
Package width
235 mm
Package depth
227 mm
Package height
95 mm
Package weight
1.28 kg
Product colour
White
Country of origin
Taiwan
Windows operating systems supported
Windows 11 x64
Bundled software
Norton Internet Security (OEM version)
LAN bandwidth management software
Warranty period
3 year(s)
DisplayPort version
1.4
Products per shipping (inner) case
1 pc(s)
Memory channels
Dual-channel
Ethernet LAN
Yes
Processor manufacturer
AMD
BLUETOOTH
Yes
Battery technology
Lithium-Manganese Dioxide (LiMnO2)
Top Wi-Fi standard
Wi-Fi 7 (802.11be)
Bluetooth version
5.4
Audio Chip
Realtek ALC4080
Number of battery cells
1
Battery weight
3 g
Maximum internal memory
128 GB
WLAN controller model
Realtek RTL8922AE
HDMI ports quantity
1
Ethernet LAN (RJ-45) ports
1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
2
USB 2.0 ports quantity
2
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity
0
HDMI version
2.1
Supported storage drive interfaces
M.2, SATA III
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity
1
Motherboard chipset
AMD X870
RAID support
Yes
VGA (D-Sub) ports quantity
0
HDCP
Yes
Headphone outputs
1
