"JetStream™ 28-Port Gigabit L2+ Managed Switch with 24-Port PoE+ PORT: 24× Gigabit PoE+ Ports, 4× Gigabit SFP Slots, RJ45/Micro-USB Console Port SPEC: 802.3at/af, 384 W PoE Power, 1U 19-inch Rack-mountable Steel Case FEATURE: Integration with JetStream™
2.169 86 RON
(TVA inclus)
Costurile de livrare nu sunt incluse
Cum te putem ajuta?
Descriere
"JetStream™ 28-Port Gigabit L2+ Managed Switch with 24-Port PoE+ PORT: 24× Gigabit PoE+ Ports, 4× Gigabit SFP Slots, RJ45/Micro-USB Console Port SPEC: 802.3at/af, 384 W PoE Power, 1U 19-inch Rack-mountable Steel Case FEATURE: Integration with JetStream™ SDN Controller,Static Routing, OAM, 802.1Q VLAN, QinQ, STP/RSTP/MSTP, IGMP Snooping, 802.1p/DSCP QoS, ACL, 802.1x, Radius/Tacacs+ Authentication, LACP, CLI, SNMP, Dual Image/Configuration, IPv6"
Ce spun clientii
Detii sau ai utilizat produsul?
Posteaza review
Detalii
SKU
TL-SG3428MP
Categorii
Brand
Number of fans
2 fan(s)
Power supply included
Yes
Quality of Service (QoS) support
Yes
VLAN support
Yes
Jumbo frames support
Yes
Web-based management
Yes
Access Control List (ACL)
Yes
MAC address filtering
Yes
System event log
Yes
Power over Ethernet (PoE)
Yes
Rate limiting
Yes
Flow control support
Yes
MAC address table
16000 entries
Rack mounting
Yes
Cloud-managed
Yes
Switch type
Managed
Port mirroring
Yes
Link aggregation
Yes
Spanning tree protocol
Yes
Installed SFP+ modules quantity
0
Basic switching RJ-45 Ethernet ports type
Gigabit Ethernet (10/100/1000)
Power source
AC
IGMP snooping
Yes
SSH/SSL support
Yes
Basic switching RJ-45 Ethernet ports quantity
24
SFP module slots quantity
4
Switch layer
L2
10G support
No
Multicast support
Yes
Switching capacity
56 Gbit/s
Installed SFP modules quantity
0
Jumbo frames
9000
Number of VLANs
4000
Broadcast storm control
Yes
BPDU filtering/protection
Yes
Packet buffer memory
12 MB
Forwarding rate
41.66 Mpps
Store-and-forward
Yes
Configuring Location Settings (CLI)
Yes
ARP inspection
Yes
Head-of-line (HOL) blocking
Yes
Active link detection
Yes
Power connector
AC-in jack
SFP+ module slots quantity
4
Console port
RJ-45/micro-USB
GARP VLAN Registration Protocol (GVRP)
Yes
Loop protection
Yes
DHCP features
DHCP client, DHCP relay, DHCP server, DHCP snooping, DHCPv6 client, DHCPv6 snooping
IP-MAC-Port binding
Yes
Power over Ethernet (PoE) power per port
30 W
Gigabit Ethernet (copper) ports quantity
24
Static port security
Yes
IP routing
Yes
Total Power over Ethernet (PoE) budget
384 W
Authentication
MAC-based authentication, Port-based authentication
Power over Ethernet plus (PoE+) ports quantity
24
Networking standards
IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3i, IEEE 802.3u, IEEE 802.3z
Virtual LAN features
MAC address-based VLAN, Port-based VLAN, Private VLAN, Tagged VLAN, Voice VLAN
Copper ethernet cabling technology
10BASE-T, 1000BASE-T
Heat dissipation
1637.14 BTU/h
Management protocols
SNMPv1/v2c/v3, LLDP/LLDP-MED
Harmonized System (HS) code
85176990
Form factor
1U
LAN port type
Gigabit
Operating temperature (T-T)
0 - 45 C
Depth
330 mm
Width
440 mm
Height
44 mm
Package width
440 mm
Package depth
528 mm
Package height
100 mm
Package weight
6.08 kg
Power consumption (max)
463.8 W
Storage temperature (T-T)
-40 - 70 C
Product colour
Black
Certification
CE, FCC, RoHS
Security algorithms
SSH, SSL/TLS
LED indicators
Yes
Quick start guide
Yes
Storage relative humidity (H-H)
5 - 90%
Operating relative humidity (H-H)
10 - 90%
User guide
Yes
Ethernet LAN data rates
10,100,1000 Mbit/s
AC input frequency
50/60 Hz
AC input voltage
100 - 240 V
