NOU
"JetStream™ 24-Port 2.5GBASE-T and 4-Port 10GE SFP+ L2+ Managed Switch with 16-Port PoE+ & 8-Port PoE++ PORT: 24× 2.5G RJ45 Ports (8× 2.5G PoE++ Ports & 16× 2.5G PoE+ Ports), 4× 10G SFP+ Slots, RJ45/Micro-USB Console Port SPEC: 802.3bt/at/af, 500 W PoE
4.665 22 RON
(TVA inclus)
Costurile de livrare nu sunt incluse
Cum te putem ajuta?
Descriere
"JetStream™ 24-Port 2.5GBASE-T and 4-Port 10GE SFP+ L2+ Managed Switch with 16-Port PoE+ & 8-Port PoE++ PORT: 24× 2.5G RJ45 Ports (8× 2.5G PoE++ Ports & 16× 2.5G PoE+ Ports), 4× 10G SFP+ Slots, RJ45/Micro-USB Console Port SPEC: 802.3bt/at/af, 500 W PoE Power, 1U 19-inch Rack-mountable Steel Case FEATURE: Integration with JetStream™ SDN Controller, Static Routing, OAM, DDM, 802.1Q VLAN, QinQ, STP/RSTP/MSTP, IGMP Snooping, 802.1p/DSCP QoS, ACL, 802.1x, Radius/Tacacs+ Authentication, LACP, CLI, SNMP, Dual Image/Configuration, IPv6"
Ce spun clientii
Detii sau ai utilizat produsul?
Posteaza review
Detalii
SKU
TL-SG3428XPP-M2
Categorii
Brand
Number of fans
3 fan(s)
Power supply included
Yes
Quality of Service (QoS) support
Yes
VLAN support
Yes
Jumbo frames support
Yes
Full duplex
Yes
Web-based management
Yes
Access Control List (ACL)
Yes
System event log
Yes
Static route
Yes
Power over Ethernet (PoE)
Yes
Rate limiting
Yes
Flow control support
Yes
Rack mounting
Yes
Cloud-managed
Yes
Switch type
Managed
10G support
Yes
Port mirroring
Yes
Link aggregation
Yes
Half duplex
Yes
Spanning tree protocol
Yes
Installed SFP+ modules quantity
0
IGMP snooping
Yes
SSH/SSL support
Yes
Stackable
No
Switch layer
L2+
Basic switching RJ-45 Ethernet ports quantity
24
SFP module slots quantity
4
Multicast support
Yes
Installed SFP modules quantity
0
Redundant power supply (RPS) support
Yes
Jumbo frames
9000
Broadcast storm control
Yes
BPDU filtering/protection
Yes
Rack mount kit
Yes
Flash memory
32 MB
MAC address table
32000 entries
Store-and-forward
Yes
Packet buffer memory
16 MB
Switching capacity
200 Gbit/s
Forwarding rate
148.8 Mpps
Configuring Location Settings (CLI)
Yes
ARP inspection
Yes
Head-of-line (HOL) blocking
Yes
Basic switching RJ-45 Ethernet ports type
2.5G Ethernet (100/1000/2500)
SFP+ module slots quantity
4
Console port
RJ-45/micro-USB
2.5G Ethernet (copper) ports quantity
24
GARP VLAN Registration Protocol (GVRP)
Yes
Loop protection
Yes
DHCP features
DHCP client, DHCP relay, DHCP server, DHCP snooping, DHCPv6 client, DHCPv6 snooping
IP-MAC-Port binding
Yes
Power source
AC/PoE
Multicast Listener Discovery (MLD) snooping
MLD v1/v2
Number of queues
8
Authentication
Guest VLAN, MAC-based authentication, Port-based authentication
Static port security
Yes
Queue scheduling algorithms
SP, WRR+SP, Weighted Round Robin (WRR)
Layer
Layer-2
Total Power over Ethernet (PoE) budget
500 W
Power over Ethernet plus (PoE+) ports quantity
16
Power over Ethernet 4PPoE (PoE++) ports quantity
8
MIB support
RFC1213, RFC2233, RFC1643, RFC1493, RFC2674, RFC2819, RFC2021, RFC2620, RFC2618, RFC2925
Virtual LAN features
MAC address-based VLAN, Port-based VLAN, Protocol-based VLAN, Stacked VLAN, Tagged VLAN, Voice VLAN
Heat dissipation
2153.45 BTU/h
IPv4 & IPv6 features
IPv4/IPv6 access-control list (ACL), IPv6 ping, IPv6 portal, IPv6 tracert
Authentication type
AAA, IEEE 802.1x, RADIUS, TACACS+
Management protocols
SNMP v1, v2c, v3
Number of static routes
48
IPv4 routes
48
IPv6 routes
48
Number of IP interfaces
32
Redundant fans support
Yes
Form factor
1U
Memory type
DRAM
LAN-Port-Type
Gigabit
LAN-Ports
24
Rackable
Yes
Redundant-PSU
Yes
Operating temperature (T-T)
0 - 40 C
Depth
330 mm
Power consumption (max)
629.1 W
Storage temperature (T-T)
-40 - 70 C
Compliance certificates
CE, Federal Communications Commission (FCC), RoHS
Sustainability compliance
Yes
Security algorithms
HTTPS, SSH, SSH-2, SSL/TLS
Cables included
AC
LED indicators
Yes
Password protection
Yes
Quick start guide
Yes
Storage relative humidity (H-H)
5 - 90%
Operating relative humidity (H-H)
10 - 90%
Ethernet LAN data rates
10,100,1000,2500,10000 Mbit/s
AC input voltage
100 - 240 V
